High Quality Fireproof Insulation Refractory Calcium Silicate Board in Construction Insulation
Calcium silicate board is an asbestos-free thermal insulation product that can withstand continuous operating temperature from650C up to1100C. It is light weight, low thermal conductivity, high strength, easy to install, reliable and durable. There are 3 grades available namely 650 &1000 & 1100 which are commonly used as furnace backup insulation in steel, petrochemical, ceramic, cement & glass industry or fire protection in building construction. It not only provides energy saving, also increases production efficiency and gives personnel protection in industrial safety aspect. And in the housing construction Calcium Silicate Board is also used as the ceiling, fireproof and heat insulation materials of wall and sound absorption materials of decoration.
Applications:
Reheating furnace -Annealing furnace-Transfer ladle -Rotary kiln-Glass tank Dip tubes and spouts Nozzles -Shuttle kiln -Tunnel kiln -Aluminum melting and holding furnace- Distribution boxes, Flow gates Hot pipe supports-Other high temperature ovens or heat processing equipments
Recommendable applications:
Commercial building: Commerce mansions, entertainment sites, shopping malls and hotels
Industrial building: Factories and warehouses
Residential building: New residential housing, renovation and decoration
Public place: Hospitals, theater and bus stations
Key Specifications/Special Features:
Specifications:
650 & 1000 C 600-1000 mmX 300-500mm X 25-100mm Speicial deimension will be as per customer request
High Strength Calcium Silicate Boards have the characters of big size, high strength and proof-fire etc. The boards can be widely used as energy-saving materials for almost all types of industrial furnaces, steel structure fire proof, partition, air duct, cable tray and stile & fire door, etc.
High Strength Calcium Silicate Boards
| Items | Unit | Index |
| Bulk Density | Kg/m3 | 800-1000 |
| Flexural Strength | MPa | 6 |
| Compressive Strength | MPa | 12 |
| Screw Holding Strength
(50×φ5mm screw,deep 25mm) | N | positive 1800
side 1500 |
| (200℃) Thermal Cond. | W/m.k | 0.13 |
| (1000℃ 3h)Thermal Cond | % | 1.5 |
Block Sizes and Dimensional Tolerances
| Length mm(±5mm) | Width mm(±4mm) | Thickness mm(+2,－1.5mm) |
| 2300-2500 | 1200 | 13-43 |
1. Light bulk weight, Low thermal conductivity
2. High bending and compressive strength
3. Good durability
4. Strong practicability in construction
5. Non-toxic, non hazardous substances
